KAPELLAindi Camera



KAPELLA, RIGEL and PROKYON cameras will complete USB 3.0 product series.
KAPELLA is a sensitive color camera for challenging samples and lighting conditions. It offers scientific users a new level of image dynamics and richness of detail. The microscope camera enables you to „Research Life”, to “Examine Elements”, to “Evaluate quality” and to “Reveal Truth”.
The operating software is included and can be installed quickly and is operated in the same way on different computer operating systems such as Macintosh, Windows and Linux OS.
Explore your personal micro universe.

  • - Color microscope camera 2.3 MPix with 60 fps
  • - 1/1.2“SONY sensor (back-illuminated)
  • - Pixel size 5.86 x 5.86 μm
  • - Full HD record at video speed
  • - Dynamic range 73.3 dB
  • - USB 3.0 integrated, no extra power supply needed
  • - Global shutter
  • - Software included
  • - Compatible to WIN 7 / 8 / 10 I MAC El Capitan I LINUX Ubuntu 14.04 LTS
IMAGE SENSOR
Type | square | utilised sensor diagonal - SONY back-illuminated CMOS I 1/1.2“ I
Pixel dimensions - 13.27 mm 5.86 x 5.86 µm
Color or monochrome - Color
Transfer method | shutter mode - All pixel scan I Global
Full sensor resolution - shutter 1920 x 1200 pixel
Cooling* - Peltier cooling -20° below ambient
CAMERA
Camera resolution in LIVE mode - 1920 x 1200 pixel (60 fps)
Camera resolution in RECORD mode - 1920 x 1200 pixel
Camera resolution in VIDEO mode - 1920 x 1080 pixel up to 60 fps
Exposure time min. - max. - 26 µs - 60
Gain - Max. 30
A/D conversion - 12 bit/14 bit (with cooling)
Absolute sensitivity threshold* - 7.0 e-
Saturation capacity* - 32.000 e-
Dynamic range* - 73.3 dB
Filter - IR cut I optional clear-glass
Hardware trigger - OUT
Power switch - Yes
Optical interface - C-mount
Power consumption - Appr. 4.5 W
Dimensions - 85 mm x 75 mm x 50 mm
Weight - Appr. 400 g
Storage options - -20°C up to +70°C
Operating temperature - +10°C up to +35°C non condensing
Warranty - 24 months
CE conformity / RoHS conformity - Yes

As we are continuously improving & developing our products, this websites may not be updated with advancements done. However, we try our best to update the website for latest information's
For complete updated specifications, please do ask for latest brochures
